The Grand Surveyor travel trailer from Forest River is a trailer that continues to provide luxury for many, many years past the first day you decide to take it off the lot! With a reimagined and fresh design, the Grand Surveyor is a new brand that will make you fall in love with just one look.



The Grand Surveyor contains inventive solutions, like a vertical toilet paper holder and toothbrush holder in the bathroom, a motion light in the pantry, a knife block and spoon holder in the kitchen, mood lights on the slide out, and heat ducts concealed in walls/cabinets. The exterior two-tone fiberglass is extremely attractive, and you will certainly look forward to using the outdoor kitchen. The 30 AMP marine grade detachable power cord will keep your trailer full of power, and the interior is filled with high-class style. Some of those stylish features are the modern dinette light, the designer Shaw® lino flooring, the shiplap wall accent board, and the custom logo laundry bag.



Get a fresh, new look on camping by choosing the fresh and new Grand Surveyor travel trailer from Forest River!

  • Grand Surveyor 267RBSS

    Grand Surveyor 267RBSS Floorplan Image

    Forest River Grand Surveyor travel trailer 267RBSS highlights: Rear Bathroom ... more about Grand Surveyor 267RBSS

    Specifications

    Sleeps 5
    Slides 1
    Length 30 ft 7 in
    Ext Width 8 ft
    Ext Height 11 ft 3 in
    Int Height 6 ft 10 in
    Hitch Weight 615 lbs
    Dry Weight 6063 lbs
    Cargo Weight 1552 lbs
    Fresh Water Capacity 40 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 30 gals
    Furnace BTU 35200 btu
    Available Beds Queen
    Refrigerator Type Residential 12V
    Refrigerator Size 10 cu ft
    Cooktop Burners 3
    Shower Size 30" x 36"
    Number of Awnings 1
    Water Heater Capacity 6 gal
    Water Heater Type Gas/Electric DSI w/Quick Recovery
    TV Info LR LED HDTV
    Awning Info 19' Electric One Touch w/LED Light Bar
    Axle Count 2
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Grand Surveyor 272FLS

    Grand Surveyor 272FLS Floorplan Image

    Forest River Grand Surveyor travel trailer 272FLS highlights: Private Bedroom ... more about Grand Surveyor 272FLS

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 1
    Length 31 ft 8 in
    Ext Width 8 ft
    Ext Height 11 ft 3 in
    Int Height 6 ft 10 in
    Hitch Weight 865 lbs
    Dry Weight 6118 lbs
    Cargo Weight 1747 lbs
    Fresh Water Capacity 40 gals
    Grey Water Capacity 40 gals
    Black Water Capacity 30 gals
    Furnace BTU 35200 btu
    Available Beds Queen
    Refrigerator Type Residential 12V
    Refrigerator Size 10 cu ft
    Cooktop Burners 3
    Shower Size 30" x 36"
    Number of Awnings 1
    Water Heater Capacity 6 gal
    Water Heater Type Gas/Electric DSI w/Quick Recovery
    TV Info LR LED HDTV
    Awning Info 21' Electric One Touch w/LED Light Bar
    Axle Count 2
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Grand Surveyor 301FKDS

    Grand Surveyor 301FKDS Floorplan Image

    Forest River Grand Surveyor travel trailer 301FKDS highlights: Bedroom Fireplace ... more about Grand Surveyor 301FKDS

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 2
    Length 36 ft 7 in
    Ext Width 8 ft
    Ext Height 11 ft 5 in
    Int Height 6 ft 10 in
    Hitch Weight 995 lbs
    Dry Weight 7603 lbs
    Cargo Weight 2192 lbs
    Fresh Water Capacity 40 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 30 gals
    Furnace BTU 32500 btu
    Available Beds King
    Refrigerator Type Residential 12V
    Refrigerator Size 10 cu ft
    Cooktop Burners 3
    Shower Size 30" x 36"
    Number of Awnings 1
    Water Heater Capacity 6 gal
    Water Heater Type Gas/Electric DSI w/Quick Recovery
    TV Info LR LED HDTV
    Awning Info 21' Electric One Touch w/LED Light Bar
    Axle Count 2
    Washer/Dryer Available Yes
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Grand Surveyor 302RLOK

    Grand Surveyor 302RLOK Floorplan Image

    Forest River Grand Surveyor travel trailer 302RLOK highlights: Window Bench ... more about Grand Surveyor 302RLOK

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 3
    Length 36 ft 7 in
    Ext Width 8 ft
    Ext Height 11 ft 5 in
    Int Height 6 ft 10 in
    Hitch Weight 875 lbs
    Dry Weight 8343 lbs
    Cargo Weight 1332 lbs
    Fresh Water Capacity 40 gals
    Grey Water Capacity 70 gals
    Black Water Capacity 30 gals
    Furnace BTU 32500 btu
    Available Beds King
    Refrigerator Type Residential 12V
    Refrigerator Size 10 cu ft
    Cooktop Burners 3
    Shower Size 30" x 36"
    Number of Awnings 1
    Water Heater Capacity 6 gal
    Water Heater Type Gas/Electric DSI w/Quick Recovery
    TV Info LR LED HDTV
    Awning Info 21' Electric One Touch w/LED Light Bar
    Axle Count 2
    Washer/Dryer Available Yes
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

Grand Surveyor Features:

Standard Features (2021)



Artisan Package (Mandatory)

  • Extended Camping (15K High Performance A/C,Heat Ducts Concealed in Wall/Cabinets (Sub-4's Ductless) w/Radiant Heat & Heat Duct to Underbelly
  • 10 Cu. Ft. Residential 12V Refrigerator, Azdel Composite Walls, PVC Roof Membrane, Porcelain Toilet, Friction Hinge Entry Door(s),
  • Black Tank Flush, Rear Camera Prep, Rooftop Solar Prep, Adjustable Platform Step - Main Entry, USB Ports
  • Stainless Steel Undermount Kitchen Sink w/Backsplash, Undermount Bath Sink w/Backsplash

Grand Surveyor Package (Mandatory)

  • Gel Coated Fiberglass Front Cap w/Integrated Windshield, Glass Sliding Shower Door, Pull-Out Drawers
  • Under Dinette, Bike/Utility Rack, Window Roller Shades T/O, TSS - Trifold Sofa Sleeper, Roof Ladder, 39" & 50" HD LED TV (by model)
  • Bluetooth Soundbar w/Speakers, 5200 BTU Fireplace, Surf(x)® Seamless Countertops, Above Slideout Mood Lighting

Turn-Key Camp Essentials (Mandatory)

  • Outdoor Kitchen - Gas Griddle, Sink, Refer & Side Shelf (Sub-4s Griddle & Shelf), Garbage Can in Bath & Kitchen, Resort Bath Hooks,
  • Toothbrush Holder, Vertical Mount Toilet Tissue Holder, Motion Sensor LED Lighting Front Baggage & Walk-In Pantry (Select Models),
  • 3/4" Stab Jack Drill Bit & Holder, Oversized Safety Assist Handle, Knife Block & Spoon Holder, Exterior LED Speakers, Custom Logo Laundry Bag,
  • Sink Covers, Euro Style Entry Door Handle, Silverware Organizer-Kitchen, High Arc Pull Down Faucet, Platinum Vanity Mirror, Pet Friendly Features

Appliances/Equipment

  • 30,000 BTU Ducted Furnace
  • 6 Gallon G/E DSI High Output Quick Recovery Hot Water Heater
  • Digital Thermostat Wall Mounted
  • Greystone® Convection Microwave (Sub-4s)
  • Range Top 3-Burner and 17" Gas Oven w/LED Lights
  • Stainless Power Range Hood w/Light

Bath

  • 12V Power Exhaust Fan
  • Heat Duct & A/C Vent (Most Models)
  • Privacy Door Lock
  • Skylight over Tub/Shower
  • Storage Cubbies Easily Stow Toiletry Kit, Blow Dryer, Linens
  • Systems Monitor Panel
  • Toilet Porcelain Thetford Underlip Flush & Single Cast Mold
  • Window Natural Light & Vented (Select Models)

Bedroom

  • 60 X 80 Residential Queen Bed
  • 72 x 80 Residential King Bed (Model Specific)
  • Bedding Embossed Coverlet
  • Cubbie Storage Area w/110V Outlets & Cup Holders
  • Double-Strut Lift Super Storage Under Bed
  • Drawer(s) On Each Side Of Bed
  • Indura-Kleen Evergreen Mattress (Antibacterial, Hypoallergenic, Mold & Mildew Resistant)
  • Oversize Wardrobes -Actually Fit Hangers & Clothes
  • Teddy Bear® Bunk Bedding (Bunk Bed Models)

Construction

  • 1 1/2" Laminated Aluminum Frame Sidewalls, Rear Wall, & Slideout Walls (R7 Closed Cell Block Foam Insulation)
  • 2" Laminated Sidewalls (R9) Closed Cell Block Foam Insulation (Select Models)
  • 2" Laminated Aluminum Perimeter Flooring & Studs (R9 Closed Cell Block Foam Insulation)
  • Aluminum Framing All Openings; Windows, Doors, Appliances
  • Roof: Trusses 16" On-Center, R14 Insulation, 3/8" Decking, (Fully Walk On)
  • Underbelly: Lami-Plast™ All Weather Protection Fully Heated & Enclosed

Electrical

  • 30 AMP Marine Grade Detachable Power Cord
  • 55 AMP Converter w/Charger
  • Battery Disconnect Mounted Front A-Frame
  • Cable & Satellite Ready
  • GFI 120V Exterior Receptacle Doorside
  • LED Amber Patio Light
  • LED Interior/Exterior Lighting

Exterior

  • Two Tone Diamond Ice & White Star Gel-Coated Fiberglass
  • Front Diamond Plate Protection
  • Dual Battery Rack
  • 4" Square Bumper w/Sewer Hose Storage
  • Magnetic Baggage Door Catches

Interior

  • 82" Ceiling Height
  • A/C Ceiling Vents Adjustable Flow & Direction
  • Adjustable Shelves in Pantry (Where Applicable)
  • Ceiling Light Switch At Entrance Door
  • Designer Shaw® Lino Flooring w/ 7 year Warranty
  • Drawers Under Dinette
  • Long Lasting Wood Drawers w/Ball Bearing Glides
  • Modern Frame Edge Cabinets w/Prism Curio Glass On Overheads
  • Shaw® Stain & Soil Resistant Carpet (Slide-Outs)
  • Vented Side Windows In Slide-Outs

Plumbing

  • 12V Demand Water Pump
  • Black Tank Flush *Artisan Package
  • City Water Fill
  • Color Coded Water Lines
  • Gravity Water Fill
  • Rotocast Fresh Water, Black, Gray Tanks (Underfloor)
  • Water Heater Bypass Kit
  • Winterization Kit

Running Gear

  • 2 5/16" Coupler
  • 205/75R15 LRD (Select Models)
  • 225/75R15 LRD (Select Models)
  • Automotive Aluminum Style Wheels
  • Lippert Axles Leaf Spring Suspension
  • Nitrogen Filled Radial Tires w/Steel Lug Inserts
  • Self Adjusting Electric Brakes
  • Spare Tire & Carrier
  • Super Lube Hubs

Safety and Security

  • Brake-Away Switch
  • Carbon Monoxide Detector
  • Dead Bolt Door Lock
  • Fire Extinguisher
  • Ground Fault Electrical Circuit(s)
  • Heavy Duty Safety Chains
  • LP Leak Detector
  • Smoke Detector
  • Tinted Safety Glass Windows

Grand Surveyor Options

  • 2ND A/C 13.5K Bedroom Requires 50 AMP Service
  • 50 AMP Service Prep 2nd A/C (Standard 301FKDS, 302RLOK)
  • Arctic Package (12V Heat Pads On Holding Tanks)
  • Bamboo Wood Plank Lino Flooring
  • Electric Stabilizer Jacks
  • FS Dinette & Chairs IPO Booth Dinette (Standard 301FKDS, 302RLOK)

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.
